Any questions about Rapid SCADA and Raspberry Pi

[IncineratorX2]

– edit – sorry wrhong thread

• This reply was modified 6 years ago by IncineratorX2.

[manjey73]

The formula name must be entered correctly, as specified in the formula itself

public double GetBit(double val, int n)
{
    UInt64 uintVal = (UInt64)val;
    return (uintVal >> n) & 1;
}

GetBit

And so it is necessary to write for all formulas

• This reply was modified 6 years ago by manjey73.

[IncineratorX2]

sorry i replied on the wrong thread.

[percy011]

I use raspberry pi 4 I found problem how to solve

• This reply was modified 3 years, 7 months ago by percy011.

[Mikhail]

Duplicated

[niel.j@raumix.co.za]

Good day, before i buy a Raspberry Pi 5 board, will there be any issues on running Rapid SCADA on the new Raspberry PI 5, or is it expected to perform the same as on Raspberry Pi 4 Board.

Kind regards
Niel

[manjey73]

Rapid Scada v6 runs on ARM v7 and higher processors
Version 5 including ARM v6

For version 6, first check dotnet support by processor type
I don’t think there will be any problems on the Raspberry Pi5

[Mikhail]

Hello,
Rapid SCADA 6 works on Raspberry Pi 3, 4 and 5.

[Mikhail]

is it expected to perform the same as on Raspberry Pi 4 Board

Yes.

[ArunRuchir]

I have successfully installed RapidScada on Raspberry Pi 4 and also created the deployment profile. Created MQTT connection and a Tabel view. Everything is working fine, except that Table view on web display is not showing current/any data. While data is visible on Device and Tag but not on web display. No specific error log also visible.
Please help if I have missed any specific setting.

[zzz]

Do you have channels bound to the tag_code or cnlnum ?

– topic needs to have a tag code defined in mqttclient.xml Properties.
– Bound to the configuration database needs to be checked in Line options

– That same tag code needs to be filled into Code col of Channels table in conf db.

For Channels related setting changes to take effect when uploading the conf db, both Server and Communicator needs to be restarted.

• This reply was modified 3 months, 3 weeks ago by zzz.

[Mikhail]

The above advice is correct.

@arunruchir, could you provide screenshots of the settings and device data page?

• This reply was modified 3 months, 3 weeks ago by Mikhail.

[ArunRuchir]

Thanks ZZZ and Mikhail,
It started working partially. I had missed mapping tag code into code col of Channels table in conf db.

Enclosed are 4 screen shots.
1) I have mapped 2 identical Channels to fetch MQTT data from broker using same topic. Its updating properly also. However, the same are not reflecting on Table view on Web page? There is mention of channel 302…… why ? and How ?
2) Although current readings started getting displayed in table, no other readings are reflected for the past. This is running for nearly 2 hour now.
3) I have to add many more devices using same MQTT Broker. Will it be a good idea to create separate lines or add more tags on same line ?

Thanks in advance for help.
https://drive.google.com/drive/folders/1t2LtMAM7Cre5t8mcVvUOPq708ua42aZf?usp=drive_link

• This reply was modified 3 months, 3 weeks ago by Mikhail.

[Mikhail]

The above link is not public.
The issue does not seem Raspberry specific. I suggest to find a proper topic related to MQTT communications for continue.
